Metal ware and furniture Powder Coatings

This product issynthesized by epoxy and polyester resins, with special properties of the twomaterials, with advantages of excellent decorative effect, mechanicalproperties and high corrosion resistance. It is widely used in indoor metalware and furniture manufacturing.

Confine of application:

metal ware;

racks, shelves;

leisure chairs;

office tables, cabinets;

Textures:

we can offer different colors and textures.


Metal ware and furniture powder coatings

Physical

properties

Gravity

1.4-1.7up to color and gloss


Grit size

100%  smaller than 100μm, special requirement should be informed


Mobility

120-140


Properties  of

Coating layer

Item

criteria

result


Gloss 60°


GB/T9754-88

1° to  95°+


Impact  test

ISO6272

GB/T1723-1993

50cm/kg


Cupping  test

ISO1520

GB/T9753-1988

8mm


Adhesion

ISO2409

GB/T  9286-1998

Grade 0


Bending  test

ISO1519

GB/T  6742-1986

2mm


Pencil  hardness

ASTMD3363

GB/T  6739-1996

1H-2H


Salt-fog  test

ISO7253

GB/T  1771-1991

500h


Anti-humidity

ISO6270

GB/T  1740-1979

1000h


Heat  resistance

110/24h(white)

Excellent  gloss retention, E≤0.3-0.5


Attention:

1. Above  parameters are gained from oil-free, rust removal cold rolling steel board of  thickness of 0.8mm,

under experimental circumstances, with coating layer  thickness of 70μm;

2. The  property data may drop down a little upon gloss reduction.


Application  conditions:

Consolidation  conditions

Standard

180(work piece temperature)15-20min


Pre-treating

Low  temperature  160(work piece temperature)15min

Fast              200(work  piece temperature) 3min

Pre-treating  methods differs from different substrates( phosphating process, sand

blasting, shot treatment)


Spraying

Corona electrostatic spraying;for other  special spraying method (user must propose requirement ahead)


Theoretical

coverage

8-10m2/kg,  coating layer thickness 60um, up to types and colors


Application

confine

Indoor


other

Packaging  and

transportation

20Kg/Carton,  with polyethylene bag, Non-dangerous articles, transportation friendly.

Avoiding  straight sunlight, humidity, heat, and contact with chemical substances;


Storing

Stored  indoors at 40℃, ventilated, dry, clean warehouse,  avoiding fire source, heat

radiators, straight sunlight, opening to the air. Warranty  period: 6 months. To be used

after checking if expired. Unfinished bags  should be sealed after opening.


Hygiene  and

security

Bags should be sealed after  working. Keep away from fire source.

Avoiding intake of powder. Catering and  smoking are forbidden in relevant

warehouse. Labor should wear anti-static  shoes, keep grounding.







Attentions:We do not recommend use of bright color series such as yellow, orange, red, ormetallic color series. For details, please contact

Guangzhou Yinda PowderCoatings Co., Ltd. In order to protect metal parts,

pre-treating must be done in good quality before coating. For details, please contact supplier of pre-treating chemicals.
